SN74LVCH16652ADL

更新日期：2024-04-01 00:04:00

产品简介：具有三态输出的 16 位总线收发器和寄存器

查看详情

SN74LVCH16652ADL 供应商

Member of the Texas Instruments Widebus™ Family
Operates From 1.65 V to 3.6 V
Inputs Accept Voltages to 5.5 V
Max tpd of 6.3 ns at 3.3 V
Typical VOLP (Output Ground Bounce) < 0.8 V at VCC = 3.3 V, TA = 25°C
Typical VOHV (Output VOH Undershoot) > 2 V at VCC = 3.3 V, TA = 25°C
Supports Mixed-Mode Signal Operation on All Ports (5-V Input/Output Voltage With 3.3-V VCC)
Ioff Supports Partial-Power-Down Mode Operation
Bus Hold on Data Inputs Eliminates the Need for External Pull-up or Pull-down Resistors
Latch-Up Performance Exceeds 250 mA Per JESD 17
ESD Protection Exceeds JESD 22 2000-V Human-Body Model 200-V Machine Model 1500-V Charged-Device Model
2000-V Human-Body Model
200-V Machine Model
1500-V Charged-Device Model

This 16-bit bus transceiver and register is designed for 1.65-V to 3.6-V VCC operation.

查看全部

数据手册	说明	数量	操作
SN74LVCH16652ADL	16-BIT BUS TRANSCEIVER AND REGISTER WITH 3-STATE OUTPUTS	12 Pages页,190K	查看
SN74LVCH16652ADL	Transceiver, Non-Inverting 2 Element 8 Bit per Element Push-Pull Output 56-SSOP	26页,1.09M	查看
