STM32G030C8T6

This is information on a product in full production. April 2020 DS12991 Rev 3 1/93 STM32G030x6/x8 Arm ? Cortex ? -M0+ 32-bit MCU, up to 64 KB Flash, 8 KB RAM, 2x USART, timers, ADC, comm. I/Fs, 2.0-3.6V Datasheet - production data Features ? Core: Arm ? 32-bit Cortex ? -M0+ CPU, frequency up to 64 MHz ? -40°C to 85°C operating temperature ? Memories – Up to 64 Kbytes of Flash memory with protection – 8 Kbytes of SRAM with HW parity check ? CRC calculation unit ? Reset and power management – Voltage range: 2.0 V to 3.6 V – Power-on/Power-down reset (POR/PDR) – Low-power modes: Sleep, Stop, Standby –V BAT supply for RTC and backup registers ? Clock management – 4 to 48 MHz crystal oscillator – 32 kHz crystal oscillator with calibration – Internal 16 MHz RC with PLL option – Internal 32 kHz RC oscillator (±5 %) ? Up to 44 fast I/Os – All mappable on external interrupt vectors – Multiple 5 V-tolerant I/Os ? 5-channel DMA controller with flexible mapping ? 12-bit, 0.4 μs ADC (up to
